Home > Products > LED Drivers (Power Supply) > 24W Dali Dimmable Led power supply

24W Dali Dimmable Led power supply

24W Dali Dimmable Led power supply

    Unit Price: USD 7.50 - 9.00 / Piece/Pieces
    Payment Type: T/T,Paypal,Western Union
    Terms of Trade: EXW
    Min. Order: 1 Piece/Pieces
    Delivery Time: 10 Days
    Packaging: common carton
    Productivity: 10000pcs/day
    Brand: HUEUC
    Transportation: Ocean,Air,EXPRESS
    Place of Origin: China
    Supply Ability: 10000pcs/day
    Certificate: ISO9001
    HS Code: 85044014
    Port: Shenzhen

Basic Info

Model No.: HDL-CV-30

Usage: Light

Output Type: Single

Driving Method: LED Constant Current

Circuit Structure: PWM Controlled

Certification: TUV, CE, ROSH, ISO9001

Power Supply Mode: Constant Current Source

Modulation System: PWM

In-Out: Step-down Type

Power Supply Voltage: AC85-265

Model: 24W 30W Plastic Dali Dimmable Led Driver

Size: 132*44*23MM

Wattage: 30w

Input Voltage: 110V /220V(CE ETL TUV SAA)

PF: >0.95

Efficiency: >80%

Warranty: 5Years

IP Rate: IP20

Output Wattage: 24 30

Output Current: 2A/1.25A/

Product Description

24W 30W plastic DALI dimmable led driver, 5 years warranty.One channel dimmable led driver fit for LED module. Compliant with SELV standards with output voltage≤60DC,efficiency>85%,Fit for class I protection lighting fixture.compatible with treaty of DALI IEC62386-102.

24W 30W plastic dali dimmable led driver


Constant Current:

Model No.PV-CC-30

Input Voltage Range:200-240V/AC&90-130V/AC

AC Frequency:48-62Hz

output model: constant current

output current :350ma/500ma/700ma/900ma

no load voltage :65Vmax

on load voltage :11-58v

output power :30w

power factory >0.95

efficiency :80%-86%

dimension :132*44*23mm



Constant Voltage:

Model No.:PV-CV-30

Input Voltage Range:200-240V/AC&90-130V/AC

AC Frequency:48-62Hz

output model :constant voltage

output current :2.4A/1.25A/

no load voltage 12V.24V.

on load voltage 12V/24V

output power 30w

power factory >0.95

efficiency 80%-86%

dimension 132*44*23mm



30w 0 10v Cc Led Driver30w 0 10v Cv Led Driver


Trade Terms


1. Payment: T/T, Western Union and paypal;

2. Production lead time :500PCS: about 10 workdays, 1000PCS: about 15 workdays;

3. Sample can be delivered within 3days;

4. Shipping freight are quoted under your requests;

5. Shipping port: Shenzhen, Mainland China;

6. Discounts are offered based on order quantities;

7. MOQ: 1 pcs.


Packaging & Shipping

1. Shipping freight are quoted under your requests;

2. Shipping port: Shenzhen, Mainland China;

3. Bubble bag ,inner box,and carton etc,

Neutral Package, or customer color box package upon requirements.


Packaging


Protection:


² Short circuit / over current / over voltage/ Over load/ Over temperature



Tips:


1. The product must be connected the LED lamps, and, can't no-load power for a long time then turning on the product


2. Do not short circuit.


3.Please refer to the instruction manual before use.


4. If not sure how to use the product,please contact us before use.



Quality guarantee:


1.The warranty period is 5 years.


2. If the product have any question during the time, we can fix it or change the same to you.


3.We can design the product according to your requirement. If you want to guarantee over 5 years,

the price could be negotiated separately.


Storage:


1.Keep Dry, don`t shock


2.Storage in below 35°C,humidity less than 75% environment


about sample and mass production:

Dear buyer arrange the sample cost and freight(if you have express account,provide it),sample time:5 working days,

after confirmed the sample, dear buyer arrange the deposit and we will finish it 10- 15 days after got the deposit,balance before deliver,your own courier or we arrange is possible.


FAQ

1.Q :.Are you a fostory or trading company?

A :We are led driver manufacturer locatde in shenzhen,china more than 6years.

2.Q :What is your market?

A :Our market all over the world, we have CE/ETL/SAA/TUV/ROHS certification.

3.Q : What if I feel confusions with the products?

A:We guarantee to provide the best aftersell service to you.so if you have any question of our product please don't hesitate to tell us.

4.Q: How do I pay for my purchase?

A: We accept the following payment methods: T/T, Western Union, PayPal.

5.Q: What about delivery time?

A: Sample 3days;Bulk order within 2weeks.

About us

Huarui Lighing, the led driver manufacturer located in Shenzhen,China 5years.

We can make 6W to 300w led driver. We have 5 kinds of LED Drivers or LED Power Supply:


1. NON dimmable led driver

2. TRIAC dimmable led driver,

3. 0-10v dimmable led driver,

4. PWM dimmable led driver

5. and DALI dimmable led drivers.


Constant current and constant voltage both ok.

All of our drivers are with CE ROHS SAA TUV, parts of them with ETL certificate.

OEM Welcome.


Our led drivers are widely used for led strip light, LED Downlight,

LED Ceiling Light, LED Tube Light, MR16 spotlight, and many kinds of other led lamps which need external drivers.
